MXT Chemical Series
MXT-EBCH pumps can operate at a maximum pressure of 150 bar and with water temperatures up to 65°C (149°F). This version, thanks to the ECOBARASS head, offers a cheaper alternative to the stainless steel, but also similar characteristics when used with salt or demineralized water. It is also preferred by the proper authorities for food and medical applications due to the absence of lead.
The painted body also provides greater protection against external aggressions. This pump is particularly so suited for fitting on system for food industry, but it can be used in the chemical sector with use of solvents*.
* See on the pump manual, the list of solvents admitted to use relative percentages.
TECHNICAL CHARACTERISTICS
| Weight | Kg | 32.5 |
| Oil capacity | lt. | 2.1 |
| Inlet | G | 1 1/4'' |
| Outlet | G | 3/4'' |
TECHNICAL CHARACTERISTICS
| Weight | Kg | 32.5 |
| Oil capacity | lt. | 2.1 |
| Inlet | G | 1 1/4'' |
| Outlet | G | 3/4'' |
Find out about all the models in the series MXT Chemical.
|
Part. No.
CODE |
Part. No.
CODE |
FLOW RATE | MAX PRESSURE | RPM | MAX POWER | TEMPERATURE | POWER TAKE-OFF | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| L/MIN | US GPM | HP | KW | |||||||||||||
| 50Hz | 60Hz | 50Hz | 60Hz | BAR | PSI | 50Hz | 60Hz | 50Hz | 60Hz | 50Hz | 60Hz | °C | °F | |||
| MXT7015EBCHL | 1.904-946.0 | 70 | 84 | 18.5 | 22.2 | 150 | 2175 | 1450 | 1740 | 26.9 | 32.3 | 19.8 | 23.8 | 65 | 149 |
|
| MXT7015EBCHR | 1.904-947.0 | 70 | 84 | 18.5 | 22.2 | 150 | 2175 | 26.9 | 32.3 | 19.8 | 23.8 | 65 | 149 |
|
||
| MXT8515EBCHL | 1.904-948.0 | 85 | 102 | 22.2 | 26.6 | 150 | 2175 | 32.3 | 38.8 | 23.8 | 28.6 | 65 | 149 |
|
||
| MXT8515EBCHR | 1.904-949.0 | 85 | 102 | 22.2 | 26.6 | 150 | 2175 | 32.3 | 38.8 | 23.8 | 28.6 | 65 | 149 |
|
||
| MXT1015EBCHL | 1.904-950.0 | 100 | 120 | 25.9 | 31.1 | 150 | 2175 | 37.7 | 45.2 | 27.7 | 33.2 | 65 | 149 |
|
||
| MXT1015EBCHR | 1.904-951.0 | 100 | 120 | 25.9 | 31.1 | 150 | 2175 | 37.7 | 45.2 | 27.7 | 33.2 | 65 | 149 |
|
||
Discover the related ACCESSORIES
This is a selection of the accessories that can be used with this Series.
If you’d like to see all the articles, go to the complete data sheet.
Double flange electric motor
Double flange electric motors
| CODE | MOTOR CONTRUCTION SHAPE | WEIGHT | RATED POWER OUTPUT | SPEED | VOLTAGE | FOR PUMP SERIES | |
|---|---|---|---|---|---|---|---|
| Kg | HP | KW | RPM | ||||
| 1.099-451.0 | IEC160L | 110 | 30 | 22 | 1450 | 400/690V | MXT, MXT High Temperature, MPX 350, MPX 500, MXT Chemical, MPX Heavy Duty, MXT Stainless Steel Chemical |
| 1.099-452.0 | IEC180L | 185 | 40 | 30 | 1450 | 400/690V | MXT, MXT High Temperature, MPX 350, MPX 500, MXT Chemical, MPX Heavy Duty, MXT Stainless Steel Chemical |
This is a selection of the accessories that can be used with this Series.
If you’d like to see all the articles, go to the complete data sheet.
Flexible coupling
Flexible couplings for electic motors
| CODE | MOTOR CONTRUCTION SHAPE | MOTOR P.T.O. Ø | PUMP P.T.O. Ø | FOR PUMP SERIES |
|---|---|---|---|---|
| 1.905-878.0 | H160 | 42 mm | 30 mm | MXT, MXT High Temperature, MPX 350, MPX 500, MXT Chemical, MPX Heavy Duty, MXT Stainless Steel Chemical |
| 1.905-879.0 | H180 | 48 mm | 30 mm | MXT, MXT High Temperature, MPX 350, MPX 500, MXT Chemical, MPX Heavy Duty, MXT Stainless Steel Chemical |
| 9.853-336.0 | H200 | 55 mm | 30 mm | MXT, MXT High Temperature, MPX 350, MPX 500, MXT Chemical, MPX Heavy Duty, MXT Stainless Steel Chemical |
This is a selection of the accessories that can be used with this Series.
If you’d like to see all the articles, go to the complete data sheet.
Hydraulic flanges and couplings kit
Flanges and couplings kit for hydraulic motors
| CODE | MOTOR CONTRUCTION SHAPE | MOTOR P.T.O. Ø | PUMP P.T.O. Ø | FOR PUMP SERIES |
|---|---|---|---|---|
| 1.905-536.0 | SAE J744 B-B | 1'' | 30 | MXT, MXT High Temperature, MPX 350, MPX 500, MXT Chemical, MPX Heavy Duty, MXT Stainless Steel Chemical |
This is a selection of the accessories that can be used with this Series.
If you’d like to see all the articles, go to the complete data sheet.
Ordinary Maintenance Tool Kit
Tool kit for ordinary maintenance
| CODE | FOR PUMP SERIES |
|---|---|
| 1.099-669.0 | MXT, MXT High Temperature, MPX 350, MPX 500, MXT Chemical, MXT Stainless Steel Chemical |
| 1.905-136.0 | MXT Chemical, MXT Stainless Steel Chemical |
This is a selection of the accessories that can be used with this Series.
If you’d like to see all the articles, go to the complete data sheet.
Extraordinary maintenance Kit
| CODE | FOR PUMP SERIES |
|---|---|
| 1.904-418.0 | MXT, MXT High Temperature, MPX 350, MPX 500, MXT Chemical, MXT Stainless Steel Chemical |
