HFR Series
HFR pumps can operate at a maximum pressure of 280 bar, flow rates up to 120 lpm, and with water temperatures up to 65°C (149F).
This model is suitable for fitting on gantry-style washing systems for heavy goods vehicles, on large vehicles for municipal cleaning services,
or misting systems or fire extinguishing systems, where its superior flow rate performance is beneficial.
TECHNICAL CHARACTERISTICS
| Weight | Kg | 49 |
| Oil capacity | lt. | 3.5 |
| Inlet | G | 1 - 1 1/4'' |
| Outlet | G | 3/4'' |
TECHNICAL CHARACTERISTICS
| Weight | Kg | 49 |
| Oil capacity | lt. | 3.5 |
| Inlet | G | 1 - 1 1/4'' |
| Outlet | G | 3/4'' |
The HFR Series is suitable for the following applications:
Find out about all the models in the series HFR.
|
Part. No.
CODE |
Part. No.
CODE |
FLOW RATE | MAX PRESSURE | RPM | MAX POWER | TEMPERATURE | POWER TAKE-OFF | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| L/MIN | US GPM | BAR | PSI | HP | KW | °C | °F | ||||
| HFR60SL | 1.099-179.0 | 60 | 15.7 | 280 | 4100 | 1000 | 43 | 31.6 | 40 | 104 |
|
| HFR60SR | 1.099-180.0 | 60 | 15.7 | 280 | 4100 | 43 | 31.6 | 40 | 104 |
|
|
| HFR80SL | 1.099-181.0 | 80 | 21.1 | 150 | 2175 | 30.5 | 22.4 | 40 | 104 |
|
|
| HFR80SR | 1.099-182.0 | 80 | 21.1 | 150 | 2175 | 30.5 | 22.4 | 40 | 104 |
|
|
| HFR105SL | 1.099-183.0 | 105 | 27.7 | 150 | 2175 | 40.3 | 29.7 | 40 | 104 |
|
|
| HFR105SR | 1.099-184.0 | 105 | 27.7 | 150 | 2175 | 40.3 | 29.7 | 40 | 104 |
|
|
| HFR120SL | 1.099-185.0 | 120 | 31.7 | 150 | 2175 | 46.1 | 33.9 | 40 | 104 |
|
|
| HFR120SR | 1.099-186.0 | 120 | 31.7 | 150 | 2175 | 46.1 | 33.9 | 40 | 104 |
|
|
| HFR60FL | 1.099-189.0 | 60 | 15.7 | 280 | 4100 | 1450 | 43 | 31.6 | 40 | 104 |
|
| HFR60FR | 1.099-190.0 | 60 | 15.7 | 280 | 4100 | 43 | 31.6 | 40 | 104 |
|
|
| HFR80FL | 1.099-191.0 | 80 | 20.9 | 280 | 4100 | 57.3 | 42.1 | 40 | 104 |
|
|
| HFR80FR | 1.099-192.0 | 80 | 20.9 | 280 | 4100 | 57.3 | 42.1 | 40 | 104 |
|
|
Discover the related ACCESSORIES
This is a selection of the accessories that can be used with this Series.
If you’d like to see all the articles, go to the complete data sheet.
Flexible coupling
Flexible couplings for electic motors
| CODE | MOTOR CONTRUCTION SHAPE | MOTOR P.T.O. Ø | PUMP P.T.O. Ø | FOR PUMP SERIES |
|---|---|---|---|---|
| 1.904-313.0 | IEC225 | 60 mm | 40 mm | HFR, HHP 500 - 1000 rpm, HHP 500 - 1450 rpm, GXT, GXT High temperature, GPX, GXX, TXT, TPX, TXX |
| 1.904-757.0 | IEC250 | 65 mm | 40 mm | HFR, HHP 500 - 1000 rpm, GXT, GXT High temperature, GPX, GXX, TXT, TPX, TXX |
This is a selection of the accessories that can be used with this Series.
If you’d like to see all the articles, go to the complete data sheet.
Hydraulic flanges and couplings kit
Flanges and couplings kit for hydraulic motors
| CODE | MOTOR CONTRUCTION SHAPE | MOTOR P.T.O. Ø | PUMP P.T.O. Ø | FOR PUMP SERIES |
|---|---|---|---|---|
| 1.905-537.0 | SAE J744 C | 1'' 1/4 | 40 | HFR, HHP 500 - 1000 rpm, HHP 500 - 1450 rpm, GXT, GXT High temperature, GPX, TXT, TPX |
This is a selection of the accessories that can be used with this Series.
If you’d like to see all the articles, go to the complete data sheet.
This is a selection of the accessories that can be used with this Series.
If you’d like to see all the articles, go to the complete data sheet.
This is a selection of the accessories that can be used with this Series.
If you’d like to see all the articles, go to the complete data sheet.
This is a selection of the accessories that can be used with this Series.
If you’d like to see all the articles, go to the complete data sheet.
This is a selection of the accessories that can be used with this Series.
If you’d like to see all the articles, go to the complete data sheet.
This is a selection of the accessories that can be used with this Series.
If you’d like to see all the articles, go to the complete data sheet.
This is a selection of the accessories that can be used with this Series.
If you’d like to see all the articles, go to the complete data sheet.
This is a selection of the accessories that can be used with this Series.
If you’d like to see all the articles, go to the complete data sheet.
This is a selection of the accessories that can be used with this Series.
If you’d like to see all the articles, go to the complete data sheet.
Ordinary Maintenance Tool Kit
Tool kit for ordinary maintenance
| CODE | FOR PUMP SERIES |
|---|---|
| 1.904-204.0 | HFR, HHP 500 - 1000 rpm, HHP 500 - 1450 rpm |
